35mm PM Linear Stepper Motor, Non Captive, Step Angle 7.5 or 15 Degree

FOB Reference Price:Get Latest Price
US $13-35 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
LDO MOTORS
Model Number:
LDO-35BYZ
Phase:
Two
Type:
Permanent Magnet
Certification:
CE, ROHS
Step Angle(degrees):
7.5°-15°
Current / Phase:
0.23-0.5A
Push Torque:
25-55N
Structure:
Non Captive
Frame size:
35mm
Leads:
4 wire
Shape:
Round
Usage:
Industrial
Protect Feature:
Enclosed
Function:
Control
Speed:
Low Speed
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard Export Packing
Port
HK
Lead Time :
2-3 WEEKS

Our 35mm Linear PM Stepper Motor series features a permanent magnet stepper motor and a non-captive design. This design allows for a compact form factor and low cost. Customize the pitch of the lead screw to adjust between travel speed and precision. Typical applications include microscope machines, medical instruments, dimming systems, inspection machines etc. Choose a baseline version or request your own customized configuration.

Features:

  • Non-captive design – motor moves along the lead screw
  • Compact permanent magnet stepper construction
  • High performance at a low cost
  • A wide range of screw sizes available
  • CE and RoHs approved
  • Customizations on request

The LDO Advantages:

  • No MOQ limited
  • Short Lead-Time
  • Quickly response in time
  • Good Pre/After Sales Service



Specification:

Non-Captive PM Linear stepper motor

Mode

Step Angle

No. of Phase

Voltage

(V)

Current

(A)

Resistance

(Ω)

Step Avail

(mm)

Push Torque

(N)

Journey

(mm)

Leads Number

35BYZ-B01

7.5

2

5

0.46

11

0.0254

55

75

4

35BYZ-B02

15

2

12

0.23

53

0.0417

25

40

4
